Honda TRX650FA 2004 Parts & Accessories

Introduced in 2003 as Honda's luxury utility-recreational flagship ATV, the Honda FourTrax Rincon 650 (TRX650FA) represented a major shift in quad engineering by bringing automotive-style transmission and suspension systems to the ATV market. Powered by a longitudinally mounted, semi-dry-sump 649 cc single-cylinder engine, the TRX650FA featured an automotive-style 3-speed automatic transmission utilizing a hydraulic torque converter rather than a traditional belt CVT. Coupled with Honda's first-ever fully independent rear suspension (IRS) on an ATV, radial tires, TraxLok 2WD/4WD selection, and an output-shaft-mounted rear hydraulic disc brake, the original Rincon focused heavily on rider comfort, high-speed trail compliance, and smooth power delivery.

• 649 cc liquid-cooled OHV 4-stroke longitudinally mounted single-cylinder engine with semi-dry-sump lubrication
• 37 mm Keihin constant-velocity carburetor with electric choke and automatic altitude compensation
• Automotive-style 3-speed automatic transmission with hydraulic torque converter, reverse, and Electronic Shift Program (ESP) handlebar controls
• TraxLok selectable 2WD/4WD system with torque-sensing front differential and direct shaft final drive
• Independent double-wishbone front suspension with dual shock absorbers providing 175 mm (6.9 in) wheel travel
• Independent Rear Suspension (IRS) with double wishbones and dual shock absorbers providing 203 mm (8.0 in) wheel travel
• Dual 180 mm hydraulic front drum/disc assembly and a single rear hydraulic disc brake mounted directly on the rear output shaft
• 25x8-12 front and 25x10-12 rear radial tires mounted on aluminum wheels
• 875 mm (34.5 in) seat height and 272 kg (600 lbs) dry weight / 285 kg (628 lbs) wet curb weight with a 17.0-litre (4.5 US gal) fuel tank capacity

Updated for the 2006 model year and continuing in production, the second-generation Honda FourTrax Rincon 680 (TRX680FA) increased engine displacement to 675 cc and added Honda's PGM-FI electronic fuel injection system. These modifications delivered improved low-end torque, instant throttle response, easy cold starting, and enhanced fuel economy. The chassis was further upgraded with dual front hydraulic disc brakes, an enlarged air intake, dual spark plug cylinder head architecture for cleaner emissions, an updated digital instrument cluster with integrated fuel metering, and reinforced double-wishbone suspension components.

• 675 cc liquid-cooled OHV 4-stroke longitudinally mounted single-cylinder engine with dual-plug cylinder head and semi-dry-sump lubrication
• Programmed Electronic Fuel Injection (PGM-FI) with 40 mm throttle body and automatic altitude compensation
• Automotive-style 3-speed automatic transmission with hydraulic torque converter, reverse, and Electronic Shift Program (ESP) manual mode
• TraxLok selectable 2WD/4WD system with front torque-sensing differential and direct front/rear shaft drive
• Independent double-wishbone front suspension providing 175 mm (6.9 in) wheel travel
• Independent Rear Suspension (IRS) double-wishbone configuration providing 203 mm (8.0 in) wheel travel
• Dual sealed 180 mm hydraulic front disc brakes and a single rear output-shaft-mounted 151 mm hydraulic disc brake
• 25x8-12 front and 25x10-12 rear radial tires on lightweight steel/aluminum wheels
• 876 mm (34.5 in) seat height and 294 kg (648 lbs) dry weight / 298 kg (658 lbs) wet curb weight with a 16.6-litre (4.4 US gal) fuel tank capacity
